Plug Valve

Plug valves control flow through a rotating plug with a passage that aligns with or blocks the pipeline. Their quarter-turn operation makes them suitable for isolation and selected flow-control duties across industrial and process systems.

Choosing a Plug Valve Manufacturer in Canada involves matching the plug design, sealing arrangement, pressure class, material and end connections to the intended service. Valves Only Canada supplies plug valve solutions subject to its available product range and applicable specifications.

Types of Plug Valves

Lubricated Plug Valve Non-Lubricated Plug Valve Eccentric Plug Valve

Plug Valve Features

  • Quarter-turn operation for opening and closing.
  • Lubricated or non-lubricated sealing arrangements, depending on design.
  • Sleeve or lining options for specified process media.
  • Body and plug materials selected for operating conditions.
  • Flanged, threaded or welded-end configurations within the applicable product scope.
  • Manual or actuated operation, where available.
  • Port arrangements designed for the required flow path.

Plug Valve Specifications

Specification Available Configuration / Standard
Size Range DN15–DN600
Pressure Rating PN10–PN100; ASME Class 150–900
Material Cast Iron, Ductile Iron, Carbon Steel, Low-Temperature Carbon Steel, Stainless Steel, Alloy Steel, Alloy 20, Monel
Grades ASTM A126 Class B; ASTM A536 Gr. 65-45-12; ASTM A216 WCB; ASTM A352 LCB; ASTM A217 WC6; ASTM A351 CF8 / CF8M / CF3 / CF3M / CN7M; ASTM A494 M35-1
Seat / Sleeve Materials PTFE, TFM, PFA, NBR, EPDM, Metal
End Connections Flanged RF / RTJ, Butt Weld, Socket Weld, Threaded
Operation Lever, Gear, Pneumatic, Electric
Standards API 599, ASME B16.34, API 598, API 607, ISO 10497, ISO 15848-1, ASME B16.10, ASME B16.5, ASME B16.25, AWWA C517

Industries Using Plug Valves

  • Oil & Gas
  • Petrochemical & Refining
  • Chemical Processing
  • Water & Wastewater
  • Power Generation
  • Mining & Mineral Processing
  • Marine & Offshore
  • Industrial Process Systems
